Deutz TCD 2015 - Main Journal Data; Fit Journal Data; Lifting Journal Data; Main Bearing Data

4
© 06/2006 8145-001
7/28
TCD 2015
Technical data
Testing and setting data
P01 93 Roughness
Surface for cylinder head gasket TCD 2015
10 Rz 20 [Rmax]
Surface for cylinder head cover TCD 2015
16 Rz 20 [Rmax]
Main running gear Crankshaft Main journal P02 03 Main journal, diameter Standard TCD 2015 108 mm P02 04 Main journal, diameter
Undersize stage 3 stages
TCD 2015 0.25 each mm
P02 06 Main journal, unroundness Wear limit TCD 2015 0.010 mm P02 07 Main journal, hardness Standard TCD 2015 50 HRC
Fit journal P02 11 Fit bearing, width Standard TCD 2015 38 mm P02 12 Fit bearing, width Oversize stage TCD 2015 38.25 mm P02 13 Fit bearing, width Limit value for oversize stage TCD 2015 38.50 mm Lifting journal P02 22 Lifting journal, diameter TCD 2015 91 mm P02 23 Lifting journal, diameter
Undersize stage 3 stages
TCD 2015 0.25 each mm
P02 25 Lifting journal, unroundness Wear limit TCD 2015 0.010 mm
P02 26 Radial run-out, crankshaft maximum permissible deviation TCD 2015 0.15 mm
Main bearing P02 34 Axial clearance of crankshaft permissible TCD 2015 0.205 - 0.392 mm ID no. Name Information Series Value Unit
-
0
.
01
-0.0
3
+6
0
+0
.
06
+0
.
06
+0
.
06
-
0
.
01
-0.0
3
