Deutz TCD 2015 - Crankcase; Removing and Installing the Crankcase Breather (Oil Separator); Removing the Crankcase Bleeding

© 06/2006 8174-001
1/6
TCD 2015
Crankcase
W 03-01-11
6
Removing and installing the crankcase breather
(oil separator)
Commercial available tools Collect leaking operating substances in
suitable vessels and dispose of according
to regulations.
Removing the crankcase bleeding
z Unscrew screw (1).
1
© 40664-0
z Loosen hose clip (1).
z Loosen hose clip (2).
z Pull out pipe (3).
z Remove intake elbow (4).
4
32
1
© 45807-0
