TCD 2015
Technical data
Testing and setting data
P02 86 Closed gap, piston ring 3
Standard
TCD 2015
0.4 - 0.7 mm
Wear limit (identification TOP in direction of piston head)
1.2 mm
P02 87 Axial clearance, 1st piston ring Wear limit TCD 2015
Measure with trape- zoidal groove wear gauge
-
P02 88 Axial clearance, 2nd piston ring Wear limit TCD 2015 0.25 mm
P02 89 Axial clearance, 3rd piston ring Wear limit TCD 2015 0.15 mm
Crankcase Camshaft bearing P03 11
Bore diameter for camshaft bearing liner in the crankcase
TCD 2015 75.000 mm
P03 12 Camshaft bearing liner, outside diameter TCD 2015 75.090 mm P03 13
Camshaft bearing liner, inside diameter
TCD 2015
69.990 mm
Camshaft bearing liner, wall thickness 2.0493 mm
P03 14 Camshaft bearing liner, inside diameter Wear limit TCD 2015 70.100 mm
P03 23 Tappet bores, diameter TCD 2015 25.000 mm
P03 24 Tappet bores, diameter Wear limit TCD 2015 25.050 mm P03 25
Installation depth of the crankshaft sealing ring (rear cover)
First assembly
TCD 2015
0.5 mm
Repairs 3.5 mm
P03 26
Installation depth of the crankshaft sealing ring (genset support)
First assembly
TCD 2015
3 mm
Repairs 7 mm
Cylinder liners P03 31 Cylinder bore Standard TCD 2015 132 mm P03 35 Fitting depth for cylinder liner TCD 2015 9.87 mm ID no. Name Information Series Value Unit
+0
.
03
0
+0
.
03
0
+0
.
05
0
+0
.
0
0
+0
.
03
0
+0
.
2
-0.2
+0
.
2
-0.2
+0.
-0.
5
+0.
-0.
5
+0
.
0
-0.0
+0
.
0
-0.0
