Deutz TCD 2015 - Tightening Specifications

4
© 06/2006 8145-001
17/28
TCD 2015
Technical data
Tightening specifications
ID no. Name Screw type Notes / Remarks Series
Pre-clam- ping value
Post- clamping value
A00 001 Clamping bracket on crankcase
Mounting feet/engine moun- ting on crankcase, elastic
TCD 2015 106 Nm
Mounting feet/engine moun- ting on crankcase, rigid oil lightly
TCD 2015 30 Nm +45°
A00 002 Clamping bracket on adapter for assembly block TCD 2015 90 Nm
A00 003 Mounting feet/engine mounting on crankcase
elastic TCD 2015 106 Nm
rigid oil lightly
TCD 2015 30 Nm +45°
A01 001 Cylinder head on crankcase
Screw can be used a max. 3 times, otherwise re- new every time they are loo- sened. Oil lightly
TCD 2015 50 Nm
+120° +120° +60°
A01 002 Rocker arm bracket on cylinder head TCD 2015 61 Nm A01 003 Lock nut valve clearance setting screw TCD 2015 20 Nm A01 004 Cylinder head cover on cylinder head oil lightly TCD 2015 22 Nm A01 005 Cylinder head cover on cylinder head hood M8x30
oil lightly hexagonal socket
TCD 2015 22 Nm
A02 001 Counterweight on crankshaft oil lightly TCD 2015 50 Nm
+30° +60° +60°
A02 010 Main bearing cover, vertical screws
Screws with washers
Screws can be used a max. 3 times, otherwise re- new every time they are loo- sened. Oil lightly
TCD 2015 50 Nm
+60° +60° +120°
