4
© 06/2006 8145-001
18/28
TCD 2015
Technical data
Tightening specifications
A02 011 Main bearing cover, horizontal screws
Screws can be used a
max. 3 times, otherwise re-
new every time they are loo-
sened.
TCD 2015 80 Nm
+30°
+30°
A02 020 Big end bearing cover on connecting rod
Renew screws every time
they are loosened.
TCD 2015 50 - 60 Nm
+60°
+60°
A03 010 Rear cover on crankcase
Insert with locking agent
DEUTZ DW 59
TCD 2015 21 Nm
A03 020 Genset support on crankcase M10 TCD 2015 55 Nm
A03 030 Lubricating oil pan on crankcase
Gasket steel beading
Observe tightening order
TCD 2015 28 Nm
TCD 2015
(Railway)
24 Nm
A03 031 Oil drain plug on lubricating oil pan
oil lightly TCD 2015 120 Nm
TCD 2015
(Railway)
120 Nm
A03 034 Half-flange on connecting flange M8x30-10.9
TCD 2015
(Railway)
30 Nm
A03 035 Connecting flange on lubricating oil pan M10x20-10.9
TCD 2015
(Railway)
30 Nm
A03 051 Valve housing (pressurestat) on crankcase oil lightly TCD 2015 50 Nm 210 Nm
A03 060 Crankcase breather Pipe clamp TCD 2015 8 Nm
A03 064 Breather pipe on intake elbow/oil separator Hose clip TCD 2015 6.5 Nm
A03 069
Breather pipe (holder) on cable harness rail TCD 2015 20 Nm
Pipe (crankcase breather) on cable harness rail
TCD 2015
(Railway)
20 Nm
ID no. Name Screw type Notes / Remarks Series
Pre-clam-
ping value
Post-
clamping
value
