TCD 2015
Technical data
Tightening specifications
A03 070 Pipe (crankcase breather) Hose clip
TCD 2015 (Railway)
6.5 Nm
A03 080 Connection housing on lubricating oil pan TCD 2015 70 Nm
A03 081 Connection housing to crankcase M12x1.5x35
Insert with locking agent DEUTZ DW 59
TCD 2015 30 Nm
+30° +30°
A03 082 Connection housing to crankcase M12x1.5x90
Insert with locking agent DEUTZ DW 59
TCD 2015 30 Nm
+60° +60°
A03 085 Cover on connection housing M8x16
Insert with locking agent DEUTZ DW 59
TCD 2015 21 Nm
A03 088 Connection housing to crankcase M12x190
Insert with locking agent DEUTZ DW 59
TCD 2015 30 Nm
+60° +60° +60°
A03 089 Connection housing to crankcase M12x175
Insert with locking agent DEUTZ DW 59
TCD 2015 30 Nm
+60° +90°
A04 001
Central screw for camshaft gear wheel on cams- haft
oil lightly TCD 2015 50 Nm +150°
A04 002 Stop cover (camshaft) on crankcase
Insert with locking agent DEUTZ DW 72
TCD 2015 22 Nm
A04 003 Camshaft gear wheel on idler gear oil lightly TCD 2015 30 Nm
A04 004 Gear wheel on camshaft for injection pumps TCD 2015 30 Nm +30° A04 005 Plug of injection pump camshaft on crankcase
Fastening screw for diverter stopper
TCD 2015 8.5 Nm
A04 011 Fastening screw for idler gear on genset support TCD 2015 80 Nm A04 012 Screw plug for bolt idler gear oil lightly TCD 2015 79 Nm A04 013 Screw for bolt idler gear M12x100 oil lightly TCD 2015 70 Nm
A04 015 Pad thrust bearing on crankcase oil lightly TCD 2015 30 Nm
ID no. Name Screw type Notes / Remarks Series
Pre-clam- ping value
Post- clamping value
