4
© 06/2006 8145-001
20/28
TCD 2015
Technical data
Tightening specifications
A04 020 Gear case cover on crankcase
TCD 2015 21 Nm
M8x35
M8x45
TCD 2015
(Railway)
21 Nm
A04 022 Cover (stop cover) on crankcase
Insert with locking agent
DEUTZ DW 72
TCD 2015 20 Nm
A05 011
Speed governor on connection housing (cranks-
haft)
TCD 2015 8 Nm
A05 012 Speed governor on cover (camshaft) TCD 2015 8 Nm
A06 001 Exhaust pipe at cylinder head
Insert with fitting compound
DEUTZ S1
TCD 2015 60 Nm
A06 002 Exhaust pipe on exhaust manifold
Insert with fitting compound
DEUTZ S1
TCD 2015 22 Nm
A06 003 Exhaust pipe on exhaust line Nut
Insert with fitting compound
DEUTZ S1
TCD 2015 18 Nm
A06 010
Exhaust manifold to connection housing TCD 2015 28 Nm
Exhaust manifold to exhaust line
Insert with fitting compound
DEUTZ S1
TCD 2015
(Railway)
35 Nm
A06 020 Exhaust turbocharger to exhaust manifold
Insert with fitting compound
DEUTZ S1
TCD 2015 35 Nm
Nut
TCD 2015
(Railway)
10 Nm 35 Nm
A06 021 Intake elbow to exhaust turbocharger
Hose clip
housing position of the hose
clip top
screw head rear
TCD 2015 5 Nm
A06 024 Tubing connection to turbocharger Hose clip
TCD 2015
(Railway)
5 Nm
ID no. Name Screw type Notes / Remarks Series
Pre-clam-
ping value
Post-
clamping
value
