Deutz TCD 2015 - Cylinder Head Data; Valve Guide Data

4
© 06/2006 8145-001
4/28
TCD 2015
Technical data
Testing and setting data
P00 32 Stroke TCD 2015 145 mm P00 40 Compression ratio
TCD 2015 17.5:1 - TCD 2015 (Railway)
16.5:1 -
P00 50 Direction of rotation looking onto the flywheel TCD 2015 counter-clockwise - P00 51 Compression pressure TCD 2015
3200-3400 (32-34)
kPa (bar)
P00 70 Spark gap TCD 2015 V06 120 °
P00 71 Ignition sequence
TCD 2015 V06 A1-B3-A3-B2-A2-B1 - TCD 2015 V08
A1-B4-A4-B1-B3-A3- B2-A2
-
P00 81 Cylinder and side view TCD 2015 T00 81 -
Cylinder head P01 01 Valve seat insert, bore (inlet)
Standard fit H6
TCD 2015 47.500 mm
P01 02 Valve seat insert, bore (outlet) Standard TCD 2015 44.500 mm
P01 03 Valve seat insert, bore (inlet) 1. oversize level TCD 2015 47.800 mm P01 04 Valve seat insert, bore (outlet) 1. oversize level TCD 2015 44.300 mm P01 05 Valve guide, bore in cylinder head Standard TCD 2015 15.000 mm
P01 06 Valve guide, bore in cylinder head 1. oversize level TCD 2015 15.100 mm P01 07 Valve guide, bore in cylinder head 2. oversize level TCD 2015 15.200 mm P01 08 Cylinder head, height Standard TCD 2015 120 mm
P01 09 Cylinder head, height Undersize TCD 2015 119.70 mm Valve guide P01 11 Valve guide, external diameter Standard TCD 2015 15.0 mm ID no. Name Information Series Value Unit
