Deutz TCD 2015 - Valve Seat Insert Data; Valve Data; Vave Seat Data

4
© 06/2006 8145-001
5/28
TCD 2015
Technical data
Testing and setting data
P01 12 Valve guide, external diameter 1. oversize level TCD 2015 15.1 mm P01 13 Valve guide, external diameter 2. oversize level TCD 2015 15.2 mm P01 14 Valve guide, inside diameter (inlet) Standard TCD 2015 8.030 mm P01 15 Valve guide, inside diameter (outlet) Standard TCD 2015 8.030 mm Valve seat insert P01 21 Valve seat insert, outside diameter (inlet) Standard TCD 2015 47.5 mm
P01 22 Valve seat insert, outside diameter (outlet) Standard TCD 2015 44.0 mm P01 23 Valve seat insert, outside diameter (inlet) 1. oversize level TCD 2015 47.800 mm P01 24 Valve seat insert, outside diameter (outlet) 1. oversize level TCD 2015 44.300 mm
Valve P01 31 Valve shaft diameter (inlet) Standard TCD 2015 7.97 mm
P01 32 Valve shaft diameter (outlet) Standard TCD 2015 7.96 mm P01 33 Valve shaft clearance (inlet) Wear limit TCD 2015 0.12 mm P01 34 Valve shaft clearance (outlet) Wear limit TCD 2015 0.14 mm P01 35 Valve edge thickness, valve head (inlet) Standard TCD 2015 1.9 mm P01 36 Valve edge thickness, valve head (outlet) Standard TCD 2015 1.5 mm
P01 37 Valve head diameter (inlet) Standard TCD 2015 46.0 mm P01 38 Valve head diameter (outlet) Standard TCD 2015 42.0 mm
Valve seat P01 45 Valve stand back dimension (inlet)
Standard (from the center of the valve head to the cylinder head sealing surface)
TCD 2015 2.5 mm
Wear limit (from the center of the valve head to the cylinder head sealing surface)
TCD 2015 1.20 - 1.60 mm
ID no. Name Information Series Value Unit
+0
.
0
0
+0
.
0
0
+0
.
07
+0.0
6
+0
.
07
+0.0
6
+0
.
07
+0.0
6
+0
.
07
+0.0
6
+0
.
00
-0.0
0
+0
.
00
-0.0
0
+0.
-0.
2
+0.
-0.
2
+0.
-0.
2
+0.
-0.
2
