© 06/2006 8226-001
1/8
TCD 2015
Fuel system
W 07-13-01
6
Removing and installing fuel pressure holding valve
Commercial available tools:
– Open wrench size SW 22
Special tools:
– Plugs/caps . . . . . . . . . . . . . . . . . 170160
– W 06-07-03 . . . . . . . . . . . . (A-bank)
Attention!
Pay attention to utmost cleanliness when
working on the fuel system.
Remove residue paint and particles of dirt
before removing.
Clean the respective affected parts care-
fully. Blow damp areas dry with compres-
sed air.
Observe the safety regulations and natio-
nal specifications for handling fuels.
Close all connections immediately after
opening with new, clean plugs/caps.
Do not remove plugs/caps until immedia-
tely before assembling.
Collect leaking operating substances in
suitable vessels and dispose of according
to regulations.
Removing fuel pressure holding valve
z Remove charge air pipe (A-bank).
W 06-07-03
z Unscrew screws (1).
z Remove the holder (2).
1
2
© 40519-0
