Deutz TCD 2015 - Page 564

TCD 2015
Fuel system
W 07-13-01
© 06/2006 8226-001
2/8
6
z Unscrew screw (1).
z Remove the holder (2).
z Unscrew hollow screw (3).
z Remove sealing rings.
1
2
3
© 40520-0
z Unscrew nut (1).
z Remove the holder (2).
1
2
© 40521-0
z Unscrew hollow screw (1).
z Remove fuel pipe (2).
z Remove sealing rings.
Hold overflow valve.
1
2
© 40522-0
