Deutz TCD 2015 - Page 565

© 06/2006 8226-001
3/8
TCD 2015
Fuel system
W 07-13-01
6
z Unscrew hollow screw (1).
z Remove sealing rings.
z Place hose pipe (2) to one side.
1
2
© 40948-0
z Hold the connector.
z Unscrew overflow valve (3).
z Remove sealing ring.
z Unscrew lock nut (1).
z Remove connector (2).
1
3
2
© 40949-0
z Visually inspect the components.
© 45848-0
