TCD 2015
Fuel system
W 07-13-01
© 06/2006 8226-001
4/8
6
Installing fuel pressure holding valve
z Mount new sealing ring.
z Screw on overflow valve (1).
1
© 40947-0
z Insert connector (2).
z Hold the connector.
z Tighten union nuts (1) with open wrench.
A07 066
Note installation position.
Connection of the hose line faces the heat
shield.
1
2
© 40949-0
z Hold the connector.
z Tighten overflow valve (1) with open wrench.
A07 067
1
2
© 40949-0
