© 06/2006 8230-001
1/6
TCD 2015
Lube oil system
W 08-04-07
6
Removing and installing the lubricating oil pan
Commercial available tools
– Packing compound
DEUTZ DW 47
– Engine oil
– W 13-03-02
Collect leaking operating substances in
suitable vessels and dispose of according
to regulations.
The appropriate operating manual should
be observed for emptying and filling the
engine.
Removing the lubricating oil pan
z Remove starter.
W 13-03-02
z Unscrew locking screw (1).
z Drain, collect and dispose of engine oil according to
regulations.
1
© 40836-0
z Oil the screw plug lightly.
z Mount new sealing ring.
z Tighten screw plug (1).
A03 031
1
© 40836-0
