Deutz TCD 2015 - Removing the Gearcase

© 06/2006 8185-001
1/6
TCD 2015
Engine control
W 04-04-09
6
Removing and installing the gearcase cover
Commercial available tools
– Packing compound
DEUTZ DW 48
– W 06-06-04
Collect leaking operating substances in
suitable vessels and dispose of according
to regulations.
Removing the gearcase
z Remove turbocharger.
 W 06-06-04
© 40700-0
z Loosen hose clip (1).
z Pull off pipe (2).
1
2
© 40701-0
