Deutz TCD 2015 - Install Crankshaft Sealing Ring

TCD 2015
Drive system
W 02-02-02
© 06/2006 8165-001
2/6
6
z Pull out the crankshaft sealing ring with assembly le-
ver.
© 36764-1
z Visually inspect all running surfaces.
© 40657-0
Install crankshaft sealing ring
z Select shim (1).
Use the shim with identification "Rep-
Stage".
1
© 36756-2
