4
© 06/2006 8145-001
8/28
TCD 2015
Technical data
Testing and setting data
P02 35 Thrust ring half, thickness
Standard
(upper and lower half)
TCD 2015 3.36 mm
P02 36 Thrust ring half, thickness
1. oversize stage=0.125 mm
(upper and lower half)
TCD 2015 3.485 mm
P02 37 Thrust ring half, thickness
2. oversize stage=0.125 mm
(upper and lower half)
TCD 2015 3.610 mm
Connecting rod
P02 41 Parallelism of the connecting rod
Permissible deviation (a)
TCD 2015
max. 0.06 mm
at a distance of (x) 100 mm
P02 42 Taper on periphery of the connecting rod
Permissible deviation (A) to (B)
TCD 2015
max. 0.10 mm
at a distance of (x) 100 mm
P02 43 Small end bush, inside diameter installed, unmachined TCD 2015 52.040 mm
P02 45
Small end bush clearance between piston pin
and small end bush
TCD 2015 0.04 - 0.063 mm
P02 46 Assembly temperature of the small end bush cooled in coolant to TCD 2015 approx. -40 °C
P02 47 Assembly temperature of the connecting rod heated up in hot-air oven to TCD 2015 max. 220 °C
Big end bearing
P02 52 Big end bearing shells, inside diameter
installed
identification (n) / top
lining spattered
TCD 2015 91.048 mm
P02 54 Big end bearing
Undersize stage
3 stages
TCD 2015 0.25 each mm
P02 55 Big end bearing, bore in connecting rod
after separation and re-assembly of rod
and cover
TCD 2015 95 mm
P02 56
Theoretical clearance between the big end bea-
ring / lifting journal
TCD 2015 0.060 - 0.136 mm
P02 57 Big end bearing clearance Wear limit TCD 2015 0.17 mm
ID no. Name Information Series Value Unit
