z Unscrew all screws (1).
1
© 40871-0
z Tighten screws (1).
z Press off the coolant pump.
z Remove gasket.
Use three studs M8 to push the coolant
pump off the genset support.
1
1
1
© 40872-0
z Remove screws.
z Remove the O-ring (1) with the disassembly tool.
z Remove the O-ring (2) with the disassembly tool.
1
2
© 36828_1
