Deutz TCD 2015 - Page 273

© 06/2006 8183-001
3/8
TCD 2015
Crankcase
W 03-11-01
6
z Insert counter bearing (1) on the flywheel side.
1
© 34712-1
z Mount spacing sleeve (1).
z Mount ball bearing (2).
z Screw on nut.
1
2
© 34713-2
z Pull out the camshaft bearings one after another.
Do not pull out the camshaft bearing (flyw-
heel side).
© 34714-2
