Deutz TCD 2015 - Page 294

TCD 2015
Engine control
W 04-05-05
© 06/2006 8187-001
2/24
6
z Unscrew screws (1).
z Place cable harness rail (2) with cable harness to
one side.
1
2
© 40410-0
z Unscrew all screws (3).
z Remove spacing sleeves.
z Unscrew all screws (2).
z Remove heat shield (1).
2
3
1
© 40411-1
z Unscrew screws (1).
z Remove the holder (2).
1
2
© 40412-0
