Deutz TCD 2015 - Page 404

TCD 2015 Railway
Exhaust system/Charging
W 06-02-05
© 06/2006 8202-001
4/10
6
z Unscrew screws (1).
1
1
© 42501-1
z Unscrew nuts (1).
z Remove washers.
z Remove holder.
z Place cables to one side.
1
1
© 45850-0
z Unscrew all nuts (1).
z Remove connecting pipe (2).
z Remove gasket.
z Visually inspect the components.
1
1
2
© 45851-1
