Deutz TCD 2015 - Page 447

© 06/2006 8209-001
3/6
TCD 2015 Railway
Fuel system
W 07-01-02
6
z Loosen lock nut (2).
z Unscrew flame glow plug (1).
z Remove insulating washer (3).
1
2
3
© 42187-1
z Unscrew adapter (1).
z Remove sealing ring.
1
© 42188-1
z Unscrew lock nut.
z Visually inspect the components.
© 42191-2
