Deutz TCD 2015 - Page 541

© 06/2006 8223-001
5/14
TCD 2015
Fuel system
W 07-10-06
6
z Unscrew hollow screw (1).
z Remove fuel pipe (2).
z Remove sealing rings.
Hold overflow valve.
1
2
© 40615-0
z Unscrew hollow screw (1).
z Remove sealing rings.
z Place fuel hose (2) to one side.
1
2
© 40616-0
z Unscrew nuts (1).
z Remove the holder (2).
1
2
© 40617-0
