Deutz TCD 2015 - Page 552

TCD 2015 Railway
Fuel system
W 07-10-06
© 06/2006 8224-001
2/6
6
z Unlock cable plug (1) and remove.
z Remove cable tie (2).
1
2
© 42108-1
z Unlock cable plug (1) and remove.
z Unlock cable plug (2) and remove.
2
1
© 45854-0
z Unscrew screws (arrows).
z Place cable harness rail with cable harness to one
side.
© 42110-1
