TCD 2015
Lube oil system
W 08-08-02
6
z Mount holder (2).
z Tighten screws (1).
 A07 044
1
2
© 40519-0
z Tighten hollow screw (1).
 A12 093
z Tighten nut (2).
 A07 044
z Tighten screw (3).
 A07 044
Hold overflow valve.
3
1
2
© 40859-0
z Install thermostat housing.
 W 09-08-04
z Install charge air pipe (A-bank)
 W 06-07-03
© 40849-0
