Deutz TCD 2015 - Page 614

TCD 2015
Lube oil system
W 08-11-10
© 06/2006 8234-001
6/10
6
z Mount new sealing ring.
z Oil the thread valve housing lightly.
z Tighten valve housing (1).
 A03 051
Do not move the adjusting bolt (2).
1
2
© 40869-0
z Mount new sealing ring.
z Tighten screw plug (1).
 A08 071
1
© 40865-0
z Mount fuel pipe (2).
z Screw on lock nut (1).
1
2
© 40973-0
