TCD 2015
Cooling system
W 09-08-01
© 06/2006 8236-001
2/2
6
z Measure end of stroke, dimension (b).
z Note measured value, dimension (b).
© 34679-2
z Determine stroke.
z Compare result with setpoint value.
P09 13
z Install thermostats.
W 09-08-02
Calculation example
Desired: Stroke
Given: -
Measured: Beginning of stroke, dimension (a)
End of stroke, dimension (b)
Dimension (b) - dimension (a)
Result: = stroke
© 34679-1
