Fujitsu PRIMERGY RX2530 M1 Upgrade And Maintenance Manual

RX2530 M1 Upgrade and Maintenance Manual 137
Hard disk drives / solid state drives
7.2.9.2 Removing the SAS expander board
Figure 60: Disconnecting power cable from the HDD backplane
Ê Disconnect the power cable from the HDD backplane.
Figure 61: Disconnecting SAS cables
Ê Disconnect the two SAS cables from the SAS expander board.
