210 Upgrade and Maintenance Manual
RX2530 M1
Expansion cards and backup units
Figure 143: Connecting the FBU adapter cable to the FBU
Ê Connect the cable end on the FBU to the FBU adapter cable as shown.
9.6.1.3 Installing the FBU
Figure 144: Position of the shoulder screw caps
