9.5.5 Replacing a TFM
Notes for variants of TFM
Depending on the RAID controller, different TFM kits are available.
9.5.5.1 Preliminary steps
Ê "Locating the defective server" on page 45
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 49
Ê "Getting access to the component" on page 49
Ê "Locating the defective component" on page 47
9.5.5.2 Removing the defective TFM
Ê Remove the depending expansion card as described in section "Removing
the expansion card" on page 194.
RAID controller TFM kit
PRAID EP400i
S26361-D3216-Axx
TFM 4G (LSZ:03-25444-05)
PRAID EP420i
S26361-D3216-Bxx
TFM 8G (LSZ:03-25444-01)
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
