Fujitsu PRIMERGY RX2530 M1

RX2530 M1 Upgrade and Maintenance Manual 319
System board and components
15.5 SATA DOM
15.5.1 Installing the SATA DOM
15.5.1.1 Preliminary steps
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 49
Ê "Getting access to the component" on page 49
15.5.1.2 Installing the SATA DOM
Figure 234: SATA DOM
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
