Upgrade and Mai
ntenance Manual
RX2530
M1
Fans
8.1.1
Numbering of the fan modules
Figure 82: Numbering of the f
an modules
1
CPU 1 fan 1/2
5
CPU 2 fan 9/10
2
CPU 1 fan 3/4
6
CPU 2 fan 1
1/12
3
CPU 1 fan 5/6
7
CPU 2 fan 13/14
4
CPU 1 fan 7/8
8
CPU 2 fan 15/16
