10.1 Basic information
Figure 157: Slots of the main memory
– The system board is equipped with 24 memory slots (12 connectors per
CPU).
– In mono processor configurations only 12 memory slots are usable.
– The system has to be equipped with at least one memory module per CPU.
– Supported capacities: 2 GB, 4 GB, 8 GB,16 GB, 32 GB or 64 GB
– Maximum amount of RAM: 1536 GB (768 GB per CPU)
