13.3.3 Replacing the front VGA board
13.3.3.1 Preliminary steps
Ê "Locating the defective server" on page 45
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 49
Ê "Getting access to the component" on page 49
Ê "Removing the front panel module" on page 275
13.3.3.2 Removing the defective front VGA board
Ê Remove the front VGA board as described in section "Removing the front
VGA board" on page 283.
13.3.3.3 Installing the new front VGA board
Ê Install the front VGA board as described in section "Installing the front VGA
board" on page 281.
13.3.3.4 Concluding steps
Ê "Installing the front panel module" on page 278
Ê "Reassembling" on page 54
Ê "Connecting the server to the mains" on page 60
Ê "Switching on the server" on page 61
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
