Fujitsu PRIMERGY RX2530 M1

166 Upgrade and Maintenance Manual RX2530 M1
Expansion cards and backup units
I When replacing network controllers, network configuration settings in the
operating system will be lost and replaced by default values. This applies
to all static IP address and LAN teaming configurations.
9.1.2.1 PLAN EM 2x 1GB T
Figure 91: DynamicLoM module D3245
Figure 92: MAC label for D3245
P0:xxxx xxxx xxx0
P1:xxxx xxxx xxx1
P1
P0
