152
Upgrade and Mai
ntenance Manual
RX2530
M1
Hard disk drives / solid st
ate drives
7.3.5.2
Removing the def
ective 3.5-inch HDD backplane
Figure 77: Disc
onnecting the cables
Ê
Disconnect all cables from the HDD backpl
ane (see blue circles).
I
If applicable, remove the OOB cable from the HDD backplane, too.
Figure 78: Connecting the OOB cable
1
Connector HDD backplane
2
Connector system board
151
