Fujitsu PRIMERGY RX2530 M1

RX2530 M1 Upgrade and Maintenance Manual 301
System board and components
15.3.1.2 Installing the UFM
Figure 218: UFM installation kit
Figure 219: Position on the system board
1 USB Flash Module (UFM) 3 UFM spacer
2 UFM nylon screw
