9.6.5 Replacing an FBU
V CAUTION!
●
Dispose of used battery properly. Keep away from children.
●
Do not throw flash backup units into the trash can. Batteries must be
disposed of in accordance with local regulations concerning special
waste.
9.6.5.1 Preliminary steps
Ê "Disabling SVOM boot watchdog functionality" on page 72
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 49
Ê "Getting access to the component" on page 49
9.6.5.2 Removing the defective FBU
Ê Remove the FBU with the holder as described in section "Removing the FBU
with the holder" on page 217 (2.5-inch HDD chassis) or section "Removing
the FBU with the holder" on page 220 (3.5-inch HDD chassis).
Ê Disconnect the FBU cable from the FBU.
Ê Remove the FBU from the holder.
9.6.5.3 Installing the new FBU
Ê Install the FBU in the holder and connect the FBU adapter cable to the FBU
as described in section "Preparing the FBU" on page 209 (2.5-inch HDD
chassis) or section "Preparing the FBU" on page 214 (3.5-inch HDD
chassis).
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: tool-less
