– In order to satisfy cooling requirements, populate memory channels on
alternating sides of the processor:
10.2 Installing a memory module
10.2.1 Preliminary steps
Ê "Disabling SVOM boot watchdog functionality" on page 72
Ê "Suspending BitLocker functionality" on page 71
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 49
Ê "Getting access to the component" on page 49
10.2.2 Selecting the memory slot
Ê Choose the memory slot according to the configuration rules in "Basic
information" on page 224.
Order CPU 1 CPU 2
1 Channel A Channel E
2 Channel C Channel G
3 Channel B Channel F
4 Channel D Channel H
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
