Fujitsu PRIMERGY RX2530 M1 Upgrade And Maintenance Manual

310 Upgrade and Maintenance Manual RX2530 M1
System board and components
15.4.1.2 Installing the TPM
Figure 227: TPM installation kit
Figure 228: Position on the system board
1 TPM (Trusted Platform Module) 3 Special screw for TPM
2 TPM spacer
I The black TPM spacer is
not used in this server.
4 TPM bit insert for TPM special
screw
/
0
1
2
