172
Upgrade and Mai
ntenance Manual
RX2530
M1
Exp
ansion cards and backup un
it
s
Figure 102: A
ssembled network
adapter D2755
9.2.2
Removing a slot bra
cket
9.2.2.1
Removing the slot
bracket
Ê
Remove the two screws.
Ê
Remove the controller fr
om the mounting t
abs on the slot bracket.
Upgrade and Repair Unit
(URU)
Hardware: 5 min
utes
T
ools:
Phillips
PH2 / (+) No. 2 screw driver
171
