Fujitsu PRIMERGY RX2530 M1

RX2530 M1 Upgrade and Maintenance Manual 321
System board and components
15.5.2 Removing the SATA DOM
15.5.2.1 Preliminary steps
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 49
Ê "Getting access to the component" on page 49
15.5.2.2 Removing the SATA DOM
Figure 237: Removing the SATA DOM
Ê Firmly remove the SATA DOM out of its connector.
15.5.2.3 Concluding steps
Ê "Reassembling" on page 54
Ê "Connecting the server to the mains" on page 60
Ê "Switching on the server" on page 61
Ê "Verifying system information backup / restore" on page 81
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
