RX2530 M1
Upgrade and Maintenance Manual 337
16 Cables
16.1 Overview cables
No. Part number Description From - to
C1 T26139-Y4015-V302 CBL FRONT PANEL System board to front panel
C2 T26139-Y3959-V303 CBL_HDD_POWER System board to 2.5-inch HDD
backplane
C3 T26139-Y3990-V302 CBL_ODD_Power System board to ODD power
C4 T26139-Y4028-V302 CBL_ODD_Data System board to ODD data,
2.5-inch HDDs
C5 T26139-Y4028-V301 CBL_ODD_Data System board to ODD data,
3.5-inch HDDs
C6 T26139-Y3994-V302 CBL_FRONT_VGA System board to front VGA
C7 T26139-Y4015-V601 CBL_OOB_HDD_2BP System board to HDD
backplane
C8 T26139-Y3959-V352 CBL_HDD_POWER System board to 3.5-inch HDD
backplane
C9 T26139-Y3999-V503 CBL_FRONT_USB System board to front USB
C10 T26139-Y3964-V303 CBL_4HDD_DATA3.5 System board to 3.5-inch HDD
backplane
C11 T26139-Y4040-V16 CBL_4HDD_SAS 2.5_onb. System board to 4x 2.5-inch
HDD backplane, R-shape
C12 T26139-Y4040-V17 CBL_4HDD_SAS 2.5_onb. System board to 4x 2.5-inch
HDD backplane, L-shape
C13 T26139-Y4040-V21 CBL_4HDD_DATA3.5 RAID controller to 3.5-inch
HDD backplane
C14 T26139-Y4040-V9 CBL_4HDD_SAS 2.5 RAID controller to 4x 2.5-inch
HDD backplane, R-shape
C15 T26139-Y4040-V11 CBL_4HDD_SAS 2.5 RAID controller to 4x 2.5-inch
HDD backplane, L-shape
C16 T26139-Y4042-V3 CBL FLEXP System board to front panel on
QRL
(The front panel on QRL and
the front panel cable are
combined in one spare part.)
