12.3 Removing the ODD
12.3.1 Preliminary steps
Ê "Removing backup and optical disk media" on page 74
Ê "Suspending BitLocker functionality" on page 71
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 49
Ê "Getting access to the component" on page 49
12.3.2 Removing the ODD
Figure 189: Disconnecting the cables from the ODD
Ê Disconnect the ODD power cable and the SATA cable from the ODD.
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools: Torx Plus 6 screw driver
