68
Upgrade and Mai
ntenance Manual
RX2530
M1
Basic hardware procedures
4.10
Handlin
g CPU air guides
4.10
.1
Removing t
he CP
U air
guides
Figure 23: Removing the CPU air
guides
Ê
Only for air guide on
C
PU 2: pull th
e hook of the extension out o
f the bracket
on the PSU cage (see close-up).
Ê
Carefully pull out the CPU air guide upward.
67
69
