218
Upgrade and Mai
ntenance Manual
RX2530
M1
Exp
ansion cards and backup un
it
s
Ê
Lift the holder out of the chassis.
9.6.3.3
Disconnecting th
e FBU cable from th
e FBU
Figure 154: Disc
onnecting the FBU
cable from
the FBU
Ê
Disconnect the FBU c
able from the FBU.
9.6.3.4
Removing t
he FBU from the hold
er
Figure 155: Removing the F
BU from the holder
Ê
Pull the FBU at a slight angle out of the holder
.
217
219
