Fujitsu PRIMERGY RX2530 M1

RX2530 M1 Upgrade and Maintenance Manual 167
Expansion cards and backup units
9.1.2.2 PLAN EM 4x 1GB T
Figure 93: DynamicLoM module D3255
Figure 94: MAC labels for D3255
P2:xxxx xxxx xxx2(6,A,E)
P3:xxxx xxxx xxx3(7,B,F)
P0:xxxx xxxx xxx0(4,8,C)
P1:xxxx xxxx xxx1(5,9,D)
P3
P1
P2
P0
