15.3.3 Replacing the UFM
15.3.3.1 Preliminary steps
Ê "Locating the defective server" on page 45
Ê "Disabling SVOM boot watchdog functionality" on page 72
Ê "Suspending BitLocker functionality" on page 71
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 49
Ê "Getting access to the component" on page 49
Ê If applicable, remove the riser module 3 as described in section "Removing
a riser module" on page 62.
15.3.3.2 Removing the defective UFM
Ê Remove the UFM as described in section "Removing the UFM" on
page 304.
Ê The UFM spacer remains on the system board.
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Software: 5 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
– combination pliers and flat nose pliers
