162 Upgrade and Maintenance Manual
RX2530 M1
Expansion cards and backup units
9.1 Basic information
9.1.1 Equipping the PCIe slots
Figure 87: PCIe slots for riser cards
iRMC
S4
external connectors
INDICATE
TPM
VGA
USB 2
USB 3
Management
LAN
Slot riser card / slot 1 and 2
PCH
JP3
SATA
1-4
USB 1
Slot riser card / slot 3
Slot riser card / slot 4
Slot 3
UFM
SERIAL 1
Slot 2
Slot 1
Slot 4
PWR3
Micro
SD
SATA
7-10
SATA 6
DOM
SATA
JP2
1
Slot LoM modules
