Fujitsu PRIMERGY RX2530 M1

RX2530 M1 Upgrade and Maintenance Manual 193
Expansion cards and backup units
9.5.1.4 Concluding steps
Ê Install the corresponding riser module as described in section "Installing a
riser module" on page 63.
Ê "Reassembling" on page 54
Ê "Connecting the server to the mains" on page 60
Ê "Updating RAID controller firmware" on page 82
Ê "Enabling Option ROM scan" on page 83
Ê "Enabling SVOM boot watchdog functionality" on page 89
Ê "Switching on the server" on page 61
Ê "Resuming BitLocker functionality" on page 95
9.5.2 Removing an expansion card
9.5.2.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 71
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 49
Ê "Getting access to the component" on page 49
Ê Remove the corresponding riser module as described in section "Removing
a riser module" on page 62.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: slot 1: Phillips PH2 / (+) No. 2 screw driver
slot 2, slot 3, slot 4: tool-less
